- Made with premium quality cold rolled carbon steel and advanced coating technology.
- Suitable for high speed and cost-effective gravure and flexographic printing.
- Special polishing technology assures smooth and sharp doctoring.
- High wear, abrasion and corrosion resistance.
- Longer service life compared to CSQ model – can be used for up to 300,000m in flexible packaging material length.
- Model: GS
- Material: Carbon Steel
- Printing Speed: ≤400m/min
- Thickness: 0.152 - 0.203mm
- Standard Size: 10, 30, 40, 50, 60mm
- Tensile Strength: 1900 -2000Mpa
- Hardness: 850 – 900HV
- Straightness: Max 0.15mm/1m
- Edge Profile: Lamella
- Suggested Application: High Speed and Cost-Effective Gravure and Flexographic Printing
