- Made with premium quality cold rolled carbon steel.
- Suitable for gravure and flexographic printing.
- Special polishing technology assures smooth and sharp doctoring.
- High wear and abrasion resistance.
- Longer service life – can be used for up to 180,000m in flexible packaging material length.
- Model: CSQ
- Material: Carbon Steel
- Printing Speed: ≤250m/min
- Thickness: 0.152 - 0.203mm
- Standard Size: 10, 30, 40, 50, 60mm
- Tensile Strength: 1850 -2000Mpa
- Hardness: 580 – 600HV
- Straightness: Max 0.15mm/1m
- Edge Profile: Lamella
- Suggested Application: Gravure and Flexographic Printing
